Plastic Injection Moulding

  • Equipped with adequate inspection facilities and back up tool room for new product developments and maintenance.
  • 7187.29 sq.Mtr.   Manufacturing facility.
  • 03 Injection Molding machines ranging from  250-660 Tons.
  • Capable of producing molded components  up to 2200 gms.
  • Capable of handling various engineering plastics.
Plastic Injection Molding Machine for High-Precision Manufacturing at Suvarna Alloys
Injection Molding Machine for Large-Scale Plastic Components Production
Injection Molding Machine for Producing High-Volume Plastic Components at Suvarna Alloys
Advanced Plastic Injection Molding Process for High-Quality Components and Engineering Plastics
Advanced Injection Molding Machine for Production
Injection Molding Machine for Engineering Plastics
SR.NO PARAMETER UOM 250 T 450 T 660 T
1 MAKE -
2 INJECTION CAPACITY MAX (GPPS) gms 646 1530 2421
3 INJECTION PRESSURE  MAX bar 1428 1421 1906
4 INJECTION RATE cc/sec 291 480 897
5 SCREW DIAMETER mm 60 80 90
6 PLASTICIZING RATE gm /sec 53 72 140
7 SCREW SPEED rpm 293 187 212
8 CLAMPING FORCE ton 250 450 660
9 CLAMP STROKE mm 830 1100 1320
10 MAXIMUM DAYIGHT mm 1080 1500*/1850 1780
11 MINIMUM MOULD HEIGHT mm 250 400*/750 460
12 PLATEN SIZE (H x V) mm 880 X 880 1200 X 1200 1400  X 1400
13 DISTANCE BET TIE ROD mm 520 X 620 830 X 830 950 x 950
14 SERVO DRIVE kw 13.6 25.1 54.4
